Fender Mustang GTX50 GTX100 User Manual Specifications
Mustang GTX50
TYPE | PR 5748 | ||
POWER REQUIREMENTS | 118 watts | ||
POWER OUTPUT | 50 watts | ||
INPUT IMPEDANCE | 1MΩ (guitar) 18kΩ (aux) | ||
SPEAKER | One 12” Celestion® G12P-80 (8Ω) | ||
FOOTSWITCH | Seven-button GTX-7 (optional, PN 0994072000) Four-button MGT-4 (optional, PN 0994071000) EXP-1 Expression Pedal (optional, PN 2301050000) | ||
FITTED AMP COVER | Optional (PN 7717475000) | ||
DIMENSIONS AND WEIGHT | Width: 19.25” (48.9 cm) Height: 17” (43.2 cm) | Depth: 9” (22.8 cm) Weight: _19.5 lbs. (8.8 kg) | |
PART NUMBERS | 2310600000 (120V) NA | 2310605000 (220V) ARG | 2310608000 (220) CN |
2310601000 (110V) TW | 2310606000 (230V) EU | 2310609000 (220V) ROK | |
2310603000 (240V) AU | 2310607000 (100V) JP | 2310613000 (240V) MA | |
2310604000 (230V) UK | |||
Mustang GTX100
TYPE | PR 5749 | ||
POWER REQUIREMENTS | 300 watts | ||
POWER OUTPUT | 100 watts | ||
INPUT IMPEDANCE | 1MΩ (guitar) 18kΩ (aux) | ||
SPEAKER | One 12” Celestion® G12FSD-100 (4Ω) | ||
FOOTSWITCH | Seven-button GTX-7 (included, PN 0994072000) Four-button MGT-4 (optional, PN 0994071000) EXP-1 Expression Pedal (optional, PN 2301050000) | ||
FITTED AMP COVER | Optional (PN 7717476000) | ||
DIMENSIONS AND WEIGHT | Width: 21” (53.3 cm) Height: 18” (45.7 cm) | Depth: 10” (25.3 cm) Weight: 22 lbs. (10 kg) | |
PART NUMBERS | 2310700000 (120V) NA | 2310705000 (220V) ARG | 2310708000 (220) CN |
2310701000 (110V) TW | 2310706000 (230V) EU | 2310709000 (220V) ROK | |
2310703000 (240V) AU | 2310707000 (100V) JP | 2310713000 (240V) MA | |
2310704000 (230V) UK | |||
Product specifications subject to change without notice.
MUSTANG™ GTX50 MUSTANG™ GTX100
产品中有害物质的名称及含量
部件名称 | 有害物质 | |||||
|---|---|---|---|---|---|---|
铅 (Pb) | 汞 (Hg) | 镉 (Cd) | 六价铬 (Cr(VI)) | 多溴联苯 (PBB) | 多溴二苯醚 (PBDE) | |
箱体 | O | O | O | O | O | O |
喇叭单元* | O | O | O | O | O | O |
电子部分 | X | O | X | O | O | O |
接线端子 | X | O | O | O | O | O |
电线 | X | O | O | O | O | O |
附件 | O | O | O | O | O | O |
本表格依据 SJ/T 11364 的规定编制。 O： 表示该有毒有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。 X： 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。 注： 含有有害物质的部件由于全球技术发展水平限制而无法实现有害物质的替代。 | ||||||
*产品含有喇叭单元时有效。
A PRODUCT OF FENDER MUSICAL INSTRUMENTS CORP. 311 CESSNA CIRCLE CORONA, CALIF. 92880 U.S.A.
AMPLIFICADOR DE AUDIO IMPORTADO POR: Fender Ventas de México, S. de R.L. de C.V. Calle Huerta #279, Int. A. Col. El Naranjo. C.P. 22785. Ensenada, Baja California, México. RFC: FVM-140508-CI0 Servicio al Cliente: 01(800) 7887395, 01(800) 7887396, 01(800) 7889433
Fender® and Mustang™ are trademarks of FMIC. Other trademarks are property of their respective owners. Copyright © 2020 FMIC. All rights reserved.
PN 7718047000 rev. c
